Indications
- Torx connection drive for greater torque control and engagement
- Cannulation to allow for precise insertion using a 1.1mm guidewire
- Tapered head to deliver a maximum compression
- Self-drilling and self-tapping triple cutting tips
- Hybrid cortical and cancellous threads optimized for osteotomy fixation
- Quick connect instrumentation with ratcheting handles
- Multiple thread lengths available upon request
Screws are intended for single use only.
- Torx connection drive for greater torque control and engagement
- Cannulation to allow for precise insertion using a 1.1mm guidewire
- Low profile head delivers maximum compression and reduces soft tissue irritation
- Self-drilling and self-tapping triple cutting tips
- Hybrid cortical and cancellous threads optimized for osteotomy fixation
- Quick connect instrumentation with ratcheting handles
- Multiple thread lengths available upon request
SYSTEM ADVANTAGES
- Low profile head cannulated titanium implants with Torx connection drive.
- Self-retaining Torx driver provides improved engagement and reduced head strippage.
- Modular caddy system contains implants and implant-specific guidewires, cannulated drills, countersink and drivers.
- Complete range of implants sizes in 2mm increments from 12mm to 22mm screw lengths.
- Screws incorporate self-drilling and self-tapping features.
- Quick connect instrumentation with ratcheting handles.
- Multiple thread lengths available upon request.
The Orion Headless Screws are indicated for use in bone reconstruction, osteotomy, arthrodesis, joint fusion,
fracture repair, and fracture fixation of bones appropriate for the size of the device. Screws are intended for
single use only.
SURGICAL TECHNIQUE
SYSTEM ADVANTAGES
■ Low profile head cannulated titanium implants with Torx connection drive
■ Self-retaining Torx driver provides improved engagement and reduced head strippage
■ Modular caddy system contains implants and implant-specific guidewires, cannulated drills, countersink
and drivers
■ Complete range of Ø 4.5mm implant sizes in 2mm increments from 20mm to 40mm and 5mm
increments from 40mm to 110mm screw lengths
■ Complete range of Ø 6.5mm implant sizes in 2mm increments from 30mm to 40mm and 5mm
increments from 40mm to 120mm screw lengths
■ Screws incorporate self-drilling and self-tapping features
■ Quick connect instrumentation with ratcheting handles
■ Multiple thread lengths available
